Balanced Weave Belt Sprocket Engagement Test

A sprocket fitted by hand into a balanced weave belt before shipment, to check that the teeth seat in the weave openings.

Belt
Balanced weave belt
Length
6 seconds
Send photos of your belt →

What you can see in this video

  • • Sprocket teeth engaging the balanced weave

What this check is for

  • ✓ Teeth seat in the weave openings
  • ✓ Pitch matches the weave

Questions about this check

What does this engagement check look for?
That the teeth sit in the weave openings. If they ride on the wires, the belt and sprocket pitch differ.
Can a balanced weave belt be matched to my existing sprockets?
Often, yes. Spiral pitch and crimp pitch are measured first, together with photos of the sprocket teeth.
