Self-Stacking Belt Running in a Freezer

A self-stacking belt running in a freezer. The stacked tiers turn together, each one carried on the side plates of the tier below — the reason a self-stacking freezer needs no drum or tier support rails.

Belt
Self-stacking belt
Length
12 seconds
Send photos of your belt →

What you can see in this video

  • • Stacked tiers turning in a freezer
  • • Side plates carrying the tier above
  • • Belt entering and leaving the stack

What this check is for

  • ✓ Even stacking while running
  • ✓ Smooth entry into and exit from the stack

Questions about this check

Why does a self-stacking freezer need no drum or tier rails?
Each tier is carried on the side plates of the tier below, so the stack supports itself while it turns.
What matters most for a replacement self-stacking belt?
Running direction (CW or CCW), side plate height and straightness, rod pitch and tier count, checked against the original.
